Siemens 3RT2015-1AP01 stýkač 3 spínacie 3 kW 230 V/AC 7 A s pomocným kontaktom Vhodné pre značku (relé): Siemens 1 ks
EAN:
Označenie výrobcu:
Objednávacie číslo:
Kategória výrobku
stýkač
Počet pólov
3-pólové
Menovité napätie
230 V/AC
Zaťažovací prúd
7 A
Výkon
3 kW
Datasheety: (PDF)
25 Ks
Počet
Celkom (39,02 € / kus)
39,02 €
bez DPH.
14-dňová lehota na vrátenie tovaru je zahrnutá v cene
Technické parametre
- Kategória výrobku
stýkač
- Typ
3RT2015-1AP01
- Konštrukčná veľkosť
S00
- Počet pólov
3-pólové
- Typ kontaktu
3 spínacie
- Pomocný kontakt
1 spínací
- Menovité napätie
230 V/AC
- Riadiace napätie (max.)
230 V/AC
- Rozsah riadiaceho napätia
230 V/AC (max)
- Spínacie napätie (max.)
400 V/AC
- Konštantný prúd (max.)
7 A
- Zaťažovací prúd
7 A
3 kW
- Vhodné pre značku
Siemens
- Vhodné pre sériu
Siemens Bauform S00
- Vlastnosti
s pomocným kontaktom
- Druh montáže
montážna lišta
- Pripojenie
skrutková svorka
IP20
- Min. teplota
-25 °C
- Max. teplota
+60 °C
- Šírka
45 mm
- V
58 mm
- Hĺbka
73 mm
- Rozmer.
(d x š x v) 150 cm x 45 mm x 58 mm
- Obsah
1 ks
- Spĺňa RoHS
áno
- Dĺžka
150 cm
- Hmotnosť
230 g
ÁNO
3 kW
3
1
7 A
18 A
230-230 V
230-230 V
Screw connection
AC
6.5 A
3 kW
2.206
- UKCA
áno
Na stiahnutie
Datasheet
Datasheet 1431023 Siemens 3RT2015-1AP01 stýkač 3 spínacie 3 kW 230 V/AC 7 A s pomocným kontaktom Vhodné pre značku (relé): Siemens 1 ks
Návod na obsluhu a bezpečnostné pokyny
Návod na obsluhu a bezpečnostné pokyny 1431023 Siemens 3RT2015-1AP01 stýkač 3 spínacie 3 kW 230 V/AC 7 A s pomocným kontaktom Vhodné pre značku (relé): Siemens 1 ks
Popis
Power contactor, AC-3 7 A, 3 kW / 400 V 1 NO, 230 V AC, 50 / 60 Hz 3-pole, Size S00 screw terminal Power contactor SIRIUS 3RT2 for switching motors.
The 3RT2 contactors are part of the modular SIRIUS system with its optimally coordinated products. They offer convincing performance from a compact design with high contact reliability. They can be combined with a variety of other components in the load feeder. Many of the device combinations have been factory tested. The contactors offer the best connection to the automation level for every application (parallel, via ASi or IO-Link): Integrated auxiliary switches reduce the complexity of your design. The front-panel terminals simplify the wiring. The 3RT2 contactors are climate-resistant, approved for worldwide use (e.g. IEC and UL/CSA) and are IE3/IE4-ready.
They are available in various sizes and in a wide performance range with AC and DC operation. In addition to screw terminals, all the devices are also available with spring-type terminals for fast, maintenance-free and vibration-proof connection.
The comprehensive range of accessories, such as auxiliary switches, auxiliary releases etc. is standardized for all sizes. The available link modules, function modules and the SIRIUS 3RV29 infeed system considerably reduce the wiring expense.
The 3RT2 power contactors replace the well-proven 3RT1 series (up to 55 kW).
Simple, efficient and always up to date - SIRIUS modular system.
The 3RT2 contactors are part of the modular SIRIUS system with its optimally coordinated products. They offer convincing performance from a compact design with high contact reliability. They can be combined with a variety of other components in the load feeder. Many of the device combinations have been factory tested. The contactors offer the best connection to the automation level for every application (parallel, via ASi or IO-Link): Integrated auxiliary switches reduce the complexity of your design. The front-panel terminals simplify the wiring. The 3RT2 contactors are climate-resistant, approved for worldwide use (e.g. IEC and UL/CSA) and are IE3/IE4-ready.
They are available in various sizes and in a wide performance range with AC and DC operation. In addition to screw terminals, all the devices are also available with spring-type terminals for fast, maintenance-free and vibration-proof connection.
The comprehensive range of accessories, such as auxiliary switches, auxiliary releases etc. is standardized for all sizes. The available link modules, function modules and the SIRIUS 3RV29 infeed system considerably reduce the wiring expense.
The 3RT2 power contactors replace the well-proven 3RT1 series (up to 55 kW).
Simple, efficient and always up to date - SIRIUS modular system.
Rady
- Upozornenie
V prípade tohto zariadenia, ktoré nie je určené na pripojenie do slaboprúdovej siete, smie pripojenie a inštaláciu vykonať iba elektrikár.
